You are here: » Product Showroom  » RF Smart card lock


SJT-212Y

Convex

Free handle

Technology Specification
Cards Quantity of Records 220pcs Reading Time <1s
Reading Range <3cm T5557 Sensor Frequency 125KHZ
M1 Sensor Frequency 13.56MHZ Working Voltage 4PCS 1.5V LR6 alkaline batternes
Static Current <15uA Dynamic Current <110mA-150mA
Lower Voltage Warning <4.8V (it can at least unlock for 250 times ) Working Temperature -10-50°C
Working Humidity 20-80% Material 201 stainless steel,plastic or metal cap
Door thickness range 32-70mm Software Interface PMS or Fedelio

Product Specification

Product Features:

-  Industrial standard main board design;

-  Special treatment on surface with automatic SMT technique;

-  Hign security lock body, standard 5 latches mortise;

-  No disturb function;


RF Mifare 1 one card system
